QSC Q-SYS CX-Q 4K8 Eight-Channel Network Amplifier

Power Networked Audio with the Q-SYS CX-Q 4K8 Eight-Channel Network Amplifier

Q-SYS CX-Q Series network amplifiers combine a legacy of robust power amplifiers, advancements in high-efficiency output devices and native network transport, control and monitoring capabilities. CX-Q 4K8 features eight channels, capable of delivering customized power output loading and a total maximum power of up to 4000 W. Low-Z, 70 V or 100 V direct drive are available on all channels.

• Simple drag-and-drop integration into your Q-SYS design, enabling network routing, advanced processing and control
• These network amplifiers are built with a 5th generation high-efficiency, Class-D hybrid powertrain design built upon the dependable PL380 PowerLight amplifier platform
• CX-Q Series network amplifiers feature FlexAmp and FAST (Flexible Amplifier Summing Technology), which combine to provide extreme flexibility in output deployment
• Eight channels of mic/line inputs (with +12 V phantom power) for additional on-ramps into Q-SYS
• PowerLight universal switchmode power supply with PFC for highest efficiency, improved audio performance and low weight
• Touch-proof Euroblock loudspeaker connections
• Eight bi-directional GPIO connections for further control and integration of third-party peripherals within Q-SYS
• Automatic energy saving modes ensure that the amplifier will draw the minimum amount of AC power while still providing outstanding audio quality

SPECIFICATIONS

Audio Performance

• Typical Distortion at 8 Ohms: 0.02 - 0.05%
• Typical Distortion at 4 Ohms: 0.04 - 0.1%
• Maximum Distortion at 4 Ohms - 8 Ohms: 1.0%
• Frequency Response: 20 Hz - 20 kHz +/- 0.3 dB
• Noise, Unweighted Output Muted: >101 dB
• Noise, Weighted Output Muted: >104 dB
• Gain, 1.2 V Setting: 35 dB
• Damping Factor: >100
• Input Impedance: >8k balanced and >4k unbalanced

Protection

• Amplifier and Load Protection: Short circuit, open circuit, over current, over voltage, thermal, RF, DC fault shutdown, active inrush limiting, on/off muting

Power

• AC Power Input: Universal power supply 100 - 240 VAC, 50 - 60 Hz

Compliance

• Agency Approvals: UL, CE, RoHS/WEEE compliant, FCC Class B (conducted and radiated emissions)

Carton Contents

• Included Accessories: IEC cable, quick start guide, Euro (green) connectors

Manufacturer: QSC Audio
Model: CX-Q 4K8
SKU: I693567-N-1-WHXX
UPC: 684284077578
